Calendar Rimming Machine Hand Operated.

Sikandar Graphics always welcome your quiries, please contact us at email:sikandargraphics@gmail.com for your requirements of selected machinery.
Machine is also available as Electric Calendar Rimming Machine in Size 30
For price, please email us  : sikandargraphics@gmail.com

Calendar Rimming Machine OR Calendar Tinning Machine is very useful and suitable machine for all kind of calendar manufactures. This machine fixes calendar rimms(variuos types of calender rimms attached with plastic tags or without tags are readily available in the market.) in double fold easily.

These rimms have a 45 degree bend lengthwise of the rim.One leg is small while the other leg is almost double.The printed calendar papers are inserted manually in the prefolded rim which has already been placed in the machine as shown in the figure.Then with the handle of the machine,it is rotated about 180 degree.This is called first stroke,with this stroke,the calendar papers are held firmly by the rim,because when we make the first stroke the smaller leg gets pressed & the longer leg gets a new bend & at the same time gets flattened.Then again we make another stroke only for more pressing the already pressed rims to make it a rigid one. At the time of first stroke a thread loop can be placed along with the papers for hanging the calendar on the wall.The purpose of the calendar rimming machine is to make a bend of 45 degree on the rim(IF it in not present already) Press the 45 degree smaller leg & at the same time make a fold in the longer leg of the rim from center & press it to overlap the previous fold.Then again pressing with second stroke.

Specification

SIZE OF MACHINE NET WEIGHT GROSS WEIGHT SPACE
36" 135 KGS 160 KGS 55"X16"X7"
23.5" 50KGS (approx) 60KGS 31"x16"x7"



Video
